Description
The Inspired Flight IF800 TOMCAT is powered by two IB388 batteries. The IB388 Battery is a hot-swappable American-made intelligent-battery tailored for use with the IF800 Tomcat. Engineered internal cell balancing, health monitoring, and cycle tracking, the IB388 ensures optimal flight time in demanding environments. The IB388 directly communicates with the IF800 Tomcat and supports NFC communication for reporting in depth status to operators. This section provides detailed guidance on harnessing the full capabilities of the IB388 for mission success.
SPECS
IB388 Specifications
| Battery Chemistry |
Lithium Polymer High-Voltage (LiHv) |
| Battery Configuration |
6 Series, 1 Parallel, Internal BMS |
| Nominal Energy |
387.6 Watt-Hours |
| Nominal Capacity |
17,000 mAh |
| Nominal Voltage |
22.8 Volts |
| Max (100% Capacity) Voltage |
26.1 Volts |
| Normal Min Voltage (1% Capacity) |
21.0 Volts |
| Minimum Safe Voltage |
19.8 Volts |
| Max Continuous Discharge |
40 Amps |
| Max Burst Discharge |
55 Amps |
| Max Charge Current |
17 Amps (1C) |
| Cut-Off Charge Current |
18 Amps |
| Max Charge Voltage (Charger Regulated) |
26.1 Volts (4.35v/Cell) |
| Cut-Off Charge Voltage (BMS Regulated) |
4.38v/Cell |
| Cell Balancing |
Controlled by BMS (<0.01v) |
| BMS Self Discharge |
To 3.8v/Cell after 48 Hours |
| Dimensions |
74 x 89 x 228 mm |
| Ambient Operating Temperature |
-10 to 45°C |
| Max Internal Temperature |
70°C |
| Storage Temperature |
10°C to 40°C |
| Life Expectancy |
150 Cycles |
| Long Term Storage |
Cycle once every 3 months |
| Status Connectivity |
Available over NFC |
IN THE BOX
(2) Inspired Flight IB388 Smart Voltage Batteries
