Description
Sold individually
- 5×7″ Mid-Range w/Bullet
- MAX Power: 350 Watts
- RMS Power: 175 Watts
- Impedance: 4-Ohm
- Ferrite Magnet
- 94dB
Specifications
Nominal Diameter
4×6″ / 102x152mm
Nominal Impedance
4 Ohm
RMS Power Handling
175W
MAX Power Handling
350W
Sensitivity (1w/1m)
90dB
Frequency Response
100Hz-12.5kHz
Recommended HI Pass Crossover
125Hz
Sold in Pair or Single
Single
Grill Included
No
Motor
Voice Coil Diameter
1″ / 25.4mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Cone Material
Paper
Bullet Material
Aluminum
Bullet Color/Finish
Red Gloss
Surround Material
Cloth
Basket Material
Steel
Basket Color/Finish
Red Gloss
Magnet Material
Ferrite
Magnet Weight
10 Oz
Displacement Volume
0.14L / 0.0049ft3
Thiele & Small Parameters
Equivalent Volume
2.44L / 0.086ft3
Excursion (one way)
1.3mm
Free Air Resonance
158Hz
Mechanical Factor
7.012
Electrical Factor
0.533
Total Factor
0.495
Mechanical Mass
3.772g
Mechanical Compliance
0.0273mm/N
BL Factor
4.87
Voice Coil Inductance
0.134 mH
Cone Area
84.95Cm2
DC Resistance
3.3 Ohms
Measurement
Overall Diameter
4.1×6.1″ / 104x155mm
Overall Depth
2.45″ / 62.2mm
Front Mount Baffle Cutout
3.4×5.6″ / 86.4x142mm
Mounting Depth
2.26″ / 57.3mm
Motor Diameter
2.76″ / 70mm
