DS18 PRO-DKH1X 2-Inch Compression Driver Kit with Horn and Spacer – 640W Max

Description

DS18 PRO-DKH1X 2″ Driver And Horn Kit Titanium 8-Ohm VC (Includes PRO-D1+PRO-HA102/BK +spacer)

Sold individually

SKU
PRO-DKH1X
Nominal Impedance
8 OHM
AES Power
160 Watts
Program Power Handling
320 Watts
Peak Power Handling
640 Watts
Sensitivity (1w/1m)
115 dB
Frequency Response
630Hz-20KHz
Recommended Hi Pass Crossover
900Hz

PRO-D1X – MOTOR

Voice Coil Diameter
2.03″ / 51.5mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Diaphragm Material
Titanium
Magnet Material
Ferrite
Magnet Weight
35 oz
Body Material
Aluminum

PRO-HA102/BK – HORN SPECIFICATIONS

Nominal Diameter
6.5″ / 165mm
Throat Diameter
2″ / 50.8mm
Sound Coverage
35° Rounded
Body Material
Aluminum
Color | Finish
Black Satin

MEASUREMENTS

Overall Diameter
6.37″ / 162mm
Overall Depth
8.3″ / 211mm
Mounting Depth
7.9″ / 201.5mm
Mounting Hole Diameter
5.7″ / 145mm
Bolt Pattern / Type
Ø 6.33″ / 161mm x 4 – 0.21″ / 5.5mm Hole
Product Weight
9 lbs
Product Dimensions
7 x 7 x 8.75
